UHD 4K Monitor >>>
*Specifications are subject to change without notice.
Specifications >>>
|
Video Input
Interface: 16ch BNC SD-SDI: Signal: 4:2:2 SMPTE 259M-C（270Mbps） Format: 525i60\625i50 Audio: SMPTE 274M-1994 Cable Length: 100m（Belden8281） Return Loss: >15DB（to 270MHz） Jitter: <0.2UI HD-SDI： Signal: 4:2:2 SMPTE 292M-C（1.5Gbps） Format: 720p29.97 Hz, 720p25 Hz, 720p24 Hz, 720p59.94 Hz, 720p50 Hz, 1080i59.94 Hz /29.97 Hz (PSF), 1080p29.97 Hz,1080i50 Hz / 25 Hz (PSF), 1080p25 Hz, 1080p23.98 Hz /24 Hz,1080p23.98(PSF) / 24PSF, 1080i50 Hz Audio: SMPTE 299M Cable Length: 100m（Belden8281） Return Loss: >15DB（5MHz to 750MHz） >10DB(750MHz to 1.5GHz) Jitter: <0.2UI 3G-SDI： Signal: 4:2:2 SMPTE 259M-C（270Mbps） Format: 1920x1080p60, 1920x1080p59.94, 1920x1080p50 Audio: SMPTE 299M Cable Length: 100m（Belden8281） Return Loss: >15DB（to 1.5GHz） >10DB(1.5GHz to 3GHz) Jitter: <0.3UI LTC Input Interface: 1ch BNC Signal: SMPTE 12M-1995（EBU-3259-E）,SMPTE 309M |
Video Output
HDMI： Interface: 4ch HDMI Signal: HDMI V1.3 Format: 1920x1080p50, 1920x1080p60, 1920x1080i50, 1920x1080i60 Cable Length: 15m SDI： Interface: 4ch BNC Signal: 3Gbps/HD-SDI SMPTE 424M/292M Format: 1920x1080p50, 1920x1080p60, 1920x1080i50, 1920x1080i60 Return Loss: >15DB（to 1.5GHz） >10DB(1.5GHz to 3GHz) Jitter: <0.3UI Communication Interface Network Interface Port: One RJ45 Signal: 10 / 100 BASE-T Serial Port (For Image Video and STL IMD): Port: One RJ45 Signal: RS-422, SMPTE207M, EBU-3245 GPI / O Interface: Port: One DB26 Number of Inputs: 16 Number of Outputs: 4 Signal: TTL-3.3V Trigger Mode: Active-low Chassis Working Environment: Operating Temperature: 0~70; Humidity: 10%~90% no condensation; Elevation: below 100 feet (3048m) Weight: 6.1kg (13.4lbs) Size: 465.5（L）x 342(W) x 44(H) mm 18.3（L）x 13.5(W) x 1.7(H) inch Input Voltage: AC 100~240V Frequency: 50-60Hz Actual Power: 60W Power Supply: Hot plug dual power supply |
